PRINTING

Print Technology Direct Thermal
Printing Resolution 203 dpi
Print Speed
(Depends on the media used.) Maximum 6 ips (152.4 mm/sec)
(Under Brother standard environment)
Maximum Print Width Maximum 2.205" (56 mm)
Maximum Print Length Maximum 39.37" (1 m)
Minimum Print Length 0.24" (6 mm)
Buttons (Power) button, (Feed) button, (Print) button
Printer Memory 6 MB or maximum 99 templates
Printer Control Commands P-touch Template2.0, Raster, ESC/P
AC Power Supply AC adapter (100 - 240 V 50/60 Hz)
Release Mode Standard: Continuous, tear off
Optional: Peeled
Size

Weight Approximately 2.96 lb (1.34 kg)
Dimensions Approximately 4.33" (W) x 8.46" (D) x 6.77" (H)
(110 mm (W) x 215 mm(D) x 172 mm (H))
Interface

USB USB Ver.2.0 (Full Speed) (mini-B, Peripheral)
Serial RS232C (Original serial cable)
Wired LAN 10/100BASE-TX
USB Host Port Supports only PA-WI-001 (optional) or barcode readers
Bluetooth
The Bluetooth interface
(optional) is required.) Bluetooth Ver.2.0+EDR (Class 2)
Bluetooth-compatible profiles
SPP (Serial Port Profile)
OPP (Object Push Profile)
BIP (Basic Imaging Profile)
WLAN
(The WLAN interface (optional) is required.) Wireless LAN IEEE802.11b/g/n
(Infrastructure Mode/Adhoc mode)
