D-Link DNR-312L 1-Bay mydlink NVR pro 9 kamer

D-Link DNR-312L 1-Bay mydlink Net. Video Rec. 9ch.OVERVIEWAll in One Surveillance Recording Solution· Reliable network camera surveillance recorder for home and DIY users· Integrated HDMI to display directly to your TV or monitor· Simply plug in your USB keyboard and mouse to control and configure· View real-time and r... více
7 182.64 Kč bez DPH
Na dotaz
8 691 Kč
Prodejna Ostrava 0 ks
ks
Vyberte si zvýhodněné balení
Množstevní slevy
Kód: DNR-312L
EAN: 790069405198
Záruka: 24
Výrobce: D-LINK
Popis a parametry

D-Link DNR-312L 1-Bay mydlink NVR pro 9 kamer

D-Link DNR-312L 1-Bay mydlink Net. Video Rec. 9ch.

OVERVIEW
All in One Surveillance Recording Solution
· Reliable network camera surveillance recorder for home and DIY users
· Integrated HDMI to display directly to your TV or monitor
· Simply plug in your USB keyboard and mouse to control and configure
· View real-time and recorded video of all nine cameras from anywhere in your home or office, or remotely via the Internet
Easy to Set Up and Use
· Effortless network camera setup and management
· User-friendly interface provides 9 channels of simultaneous live view, recording, and playback and PTZ control
· Stand-alone device, eliminates the need for a dedicated computer
· Continuous or scheduled recording with automatic overwrite function
Flexible and Scalable
· One-bay SATA 3.5” HDD interface, up to 6 TB of hard disk storage space of recorded video1
· Supports D-Link network cameras
· Power fail recovery recording
· One 10/100/1000 Mbps auto-MDIX Fast Ethernet LAN port
· M-JPEG, MPEG4 or H.264 video format
· Record up to 1080p full HD video resolution

SPECIFICATIONS
GENERAL
Standards
· IEEE 802.3/u/z
· Auto MDI/MDI-X
· SATA I, II, III
HDD1
· Reformat Disk
· Up to 6 TB HDD
· EXT3 file system
Two Reset Modes
· Reset firmware GUI button
· HW reset button (hold for 10 seconds)
Reset Button
· Reset to factory default
Performance
Flash ROM
· 128 MB
RAM
· 1024MB DDR III
Network Interface
· Gigabit Ethernet LAN port (10/100/1000 Mbps)
I/O Ports
· RJ-45 port
· DC-in jack
· HDMI
· 2 x USB 2.0 port (Mouse, UPS, Flash Disk, HDD with external power)
· 3.5mm audio input x 1, output x 1
· Power Adapter DC 12 V/3 A

SOFTWARE FEATURES
OS
· Linux
Supported Cameras
· Supports all D-Link network cameras and megapixel resolution
System Requirements for Web Interface
· Browser: Internet Explorer, Firefox, Chrome, or Safari
Recording Performance
· First video profile:
o H.264 at 720p at 270 fps or 1080p at 135 fps
· Secondary video profile:
o H.264 at VGA at 135 fps
Camera Search
· UPnP
Audio and Video Recording
· Synchronised audio & video recording
Compression Format
· H.264, MPEG-4, M-JPEG
Video Setting
· Resolution, quality, frame rate, enable audio, go to camera interface
Recording Type
· Record by schedule, manual, and event-based recording
· Motion-triggered recording
Remote Live View
· Support mydlink™ View-NVR mobile app for iOS and Android devices
· Supports mydlink™ porta
· Supported via browser
Remote Live View Control
· Live view, preset/go, patrol, focus, PTZ functions, snapshot, full screen, digital zoom
· e-map
Remote Playback Control
· Playback with normal, fast forward/rewind and step forward/rewind
Remote Playback
· Supported via browser and NVR client
· Playback system with timeline GUI, search by event, area, cameras, date, and time
· Browser or NVR Remote Client support four channel simultaneous playback
· Digital zoom
Overwrite Recording
· Auto recycling when disk storage is full
File Export
· Local : Export videos to AVI
· Remote: Export videos to AVI or ASF file
· Export images to BMP or JPG file
User Account
· Additional accounts can be created to allow users system access and specify authorisation for camera channels, PTZ
DDNS
· D-Link DDNS and DynDns server support
System Time
· Set the system time (D-Link NTP, input time, sync with computer, Daylight Saving Time)
Remote Backup
· Remote backup software can backup raw data to redundant storage
System Status
· Camera status
· Still picture EMAP support
· System status
Network Service Protocols
· IPV4, ARP, TCP, UDP, ICMP
· DHCP Client
· NTP Client
· DNS Client
· DDNS Client
· SMTP Client
· FTP Client
· HTTP Server
· IP filtering
· UPnP
· HTTPS
User Interface
· HTTP Web browser
· mydlink™ portal
· Smart phone
· NVR Search utility
Package Contents
· mydlink™ Network Video Recorder with HDMI
· Power Adapter
· Ethernet Cable
· Quick Installation Guide
· CD-ROM with:
o Software
o Product Documentation

PHYSICAL
Weight
· 0.425 kg (0.93 lbs)
Maximum Power Consumption
· 30 W
Temperature
· Operating: 0 to 40 °C
· Storage: -20 to 70 °C
Humidity
· 5% to 90% non-condensing
Certifications
· CE
· FCC
· RoHS
· BSMI
Dimensions
· 141.6 x 49.8 x 173 mm

1. Hard disk not included.
Záznamové médium
HDD
LAN
Ano
Napájení
Ze sítě 240V AC
Rozměry (Š x V x H)
5 x 14 x 17
Rychlost LAN max.
1000 Mbps
Optika
Ne
Počet LAN portů
1
Typ rozhraní
LAN
Rozlišení
1920 x 1080 (FullHD)
POE
Ne
