MSI MAG 321CUPDF Gaming monitor 31,5" Rapid VA zakřivený/3840x2160(UHD)/160Hz (320Hz - FHD)/0,5ms/2xHDMI/DP/USB-C/výšk.nast./černá

Website Name MAG 321CUPDF
Color ID1/Black-Black
Local Dimming NA
Display
Screen Size 31.5" (80.01 cm)
Active Display Area (mm) 596.16(H) x 335.34(V)
Curvature Curve 1500R
Panel Type Rapid VA
Resolution 3840x2160 (UHD)
Pixel pitch (mm) 0.18159(H)x0.18159(V)
Aspect Ratio 16:9
Dynamic Refresh Rate technology AMD FreeSync™ Premium
Dynamic Refresh Rate Activated Range UHD : 60~160Hz, FHD : 60~320Hz
HDR (High dynamic range) DisplayHDR 400
SDR Brightness (nits) 350
HDR Brightness (Peak nits) 400
Contrast Ratio 3000:1
DCR (Dynamic Contrast Ratio) 100000000:1
Signal Frequency UHD:180~317 KHz(H) / 60~160 Hz(V), FHD:180~356 KHz(H) / 60~320 Hz(V)
Refresh Rate UHD:160HZ, FHD:320Hz
Response Time (MPRT) 1ms(MPRT)
Response Time (GTG) 0.5ms
Response Time (Tr + Tf) 7.247ms
View Angles 178°(H)/178°(V)
NTSC (CIE1976 area percentage/overlap) 119%/88%
NTSC (CIE1931 area percentage/overlap) 95%/84%
sRGB (CIE1976 area percentage/overlap) 136%/99%
sRGB (CIE1931 area percentage/overlap) 134%/100%
Adobe RGB (CIE1976 area percentage/overlap) 117%/93%
Adobe RGB (CIE1931 area percentage/overlap) 99%/88%
DCI-P3 (CIE1976 area percentage/overlap) 108%/97%
DCI-P3 (CIE1931 area percentage/overlap) 98%/94%
Rec.709 (CIE1976 area percentage/overlap) 136%/99%
Rec.709 (CIE1931 area percentage/overlap) 134%/100%
Rec.2020 (CIE1976 area percentage/overlap) 79%/78%
Rec.2020 (CIE1931 area percentage/overlap) 70%/70%
Quantum Dot Film NA
Surface Treatment Anti-glare
Touch Screen Non-touch
Display Colors 1.07B
Color bit 10 bits (8 bits + FRC)
Note_DP UHD:3840 x2160 (Up to 160Hz), FHD:1920 x 1080 (Up to 320Hz)
Note_HDMI UHD:3840 x2160 (Up to 160Hz), FHD:1920 x 1080 (Up to 320Hz)
Note_DVI N/A
VESA DisplayHDR
VESA ClearMR
Delta E
I/O Ports
HDMI 2
HDMI version 2.1
HDMI HDCP version 2.3
DisplayPort 1
DisplayPort version 1.4a
DisplayPort HDCP version 2.3
Thunderbolt NA
Thunderbolt version NA
Thunderbolt HDCP version NA
USB Type C (DisplayPort Alternate) 1
DVI NA
D-Sub NA
Line-in NA
Mic-in NA
Mic-in upstream NA
Headphone-out 1
Audio Combo NA
USB 2.0 Type A NA
USB 2.0 Type B NA
USB 2.0 Micro USB Type B
USB 2.0 Type C NA
USB 3.2 Gen 1 Type A NA
USB 3.2 Gen 1 Type B NA
USB 3.2 Gen 1 Type C NA
USB 3.2 Gen 2x2 Type C NA
USB 3.2 Gen 2x2 Type A NA
Card reader N/A
Lock type Kensington Lock
Speaker NA
Webcam NA
Lan Port
Power
Country EU
Territory EU
Entity EU OBD
Power Type External Adaptor 19V 4.74A
Power Input 100~240V, 50/60Hz
On-mode Power Consumption (KWh/1000h) 31.4
Annual Energy Consumption (KWh) N/A
Standby-mode Power Consumption (W) 0.5
Off-mode Power Consumption (W) 0.3
Energy Efficiency Rating F
Adapter's KC safety Number N/A
Power Cord Type C5
QC Output NA
QC Output Power NA
PD Output YES
PD Output Power 15W
Warranty
Warranty 36M
Design
Adjustment (Tilt) -5° ~ 20°
Adjustment (Swivel) NA
Adjustment (Height) 0 ~ 130 mm
Adjustment (Pivot) NA
VESA Mounting 100x100mm
Frameless Design Yes
Console Mode YES
HDMI CEC YES
Firmware Update YES
Stand Attachment Method
Stand Type
Stand with Integrated Mini PC Mount
KVM Version
PIP/PBP
Optix Scope
Smart Crosshair
Remote Display
AI Gaming
MSI OLED Care
Scaler FW Update
Carton
Carton Item (SG14) SG14-M1S166A-MNT
pcs/Carton 1
Pallet
pallet Q'ty (by air) pcs 14
Q'ty/20cy (by air) pcs 140
Q'ty/40cy (by air) pcs 294
Dimension (L)(by air) mm 1200
Dimension (W)(by air) mm 1000
Dimension (H)(by air) mm 1170
Net Weight (by air) kg 134.68
Gross Weight (by air) kg 149.68
pallet Q'ty (by sea) pcs 28
Q'ty/20cy (by sea) pcs 280
Q'ty/40cy (by sea) pcs 588
Dimension (L)(by sea) mm 1200
Dimension (W)(by sea) mm 1000
Dimension (H)(by sea) mm 2216
Net Weight (by sea) kg 269.36
Gross Weight (by sea) kg 284.36
Dimension & Weight (product)
Product Dimension with Stand (WxDxH) (mm) 711 x 267 x 534
Product Dimension with Stand (WxDxH) (inch) 27.99 x 10.51 x 21.02
Product Dimension without Stand (WxDxH) (mm) 711 x 99 x 423
Product Dimension without Stand (WxDxH) (inch) 27.99 x 3.9 x 16.65
Stand Dimension (WxDxH) (mm) 470 x 267 x 410
Stand Dimension (WxDxH) (inch) 18.5 x 10.51 x 16.14
Weight (Net kg) 6.6
Weight (Net lbs) 14.55
Weight Without Stand (kg) 4.8
Weight Without Stand (lbs) 10.58
Dimension & Weight (box)
Inside Carton Dimension (WxDxH) (cm) 94.7 x 16.2 x 52
Inside Carton Dimension (WxDxH) (inch) 37.28 x 6.38 x 20.47
Outer Carton Dimension (WxDxH) (cm) 95.7 x 18 x 54
Outer Carton Dimension (WxDxH) (inch) 37.68 x 7.09 x 21.26
Weight (Gross kg) 9.6
Weight (Gross lbs) 21.16
Accessories
DisplayPort Cable 1
DisplayPort Cable Version 1.4a
HDMI Cable 0
HDMI Cable Version 0
DVI Cable 0
DVI Cable Version NA
USB Type A to Micro USB Type B cable
USB Type A to Type B Cable 0
USB Type C to Type A Cable 0
USB Type C to Type C Cable 0
Thunderbolt Cable 0
VGA Cable 0
3.5mm audio Cable 0
3.5mm combo audio Cable 0
3.5mm Mic Cable 0
Power Cord 1
AC Adaptor 1
Quick Guide 1
Warranty Card 0
Mouse Bungee Unit 0
VESA Screw 4
Switch Case 0
Portable Screen Protection Case 0
Monitor Hood 0
Speaker (Accessories) 0
Model Info
Segment Name2 MAG 321CU
Segment Name MAG
Series Name LCD
Segment Name3 MAG 321CUPDF
Extra Info
EOL Date
Barcode Info
UCC14 10824142381158
UPC 824142381151
JAN
EAN 4711377257060
