SCYTHE KF9215FD25-P Kaze Flex 92mm Slim PWM 300-2500rpmSCYTHE KAZE-FLEX 92 Slim PWM 2500rpm
Size Original design Thin type 16mm thick 92mm square fan
· 92mm square case fan "KAZE FLEX", thin model with thickness of 16mm
· PWM variable 300-2500rpm
Sealed Precision FDB
· Highly oil-retaining ability that suppresses volatilization and leakage due to the completely sealed bearing structure with the oil-filled cap removed.
· The fluid bearing structure that stores oil in the space between the rotating shaft and the bearing provides a high lubrication effect and quietness. The bearing uses a high-strength and high-durability high alloy to achieve low friction and long life.
· Uses high-quality lubricating oil that can withstand high temperatures of 200-250C
Shock absorbing rubber pad
-Excellent vibration absorption and fan stability.
Extender cable specifications
· The fan cable is usually 30 cm. Can be extended up to 50 cm with an extension cable
· 96 (W) x 170 (H) x 20 (D) mm
/ 105 g
92mm square case fan "KAZE FLEX SLIM"
92mm square case fan "KAZE FLEX", 16mm thick thin model
PWM variable 300-2500rpm
Sealed Precision FDB
Adopts a completely sealed bearing structure that eliminates the oil-sealed cap.
This realizes a high holding capacity that minimizes oil volatilization and leakage
Oil in the space between the rotating shaft and the bearing Highly effective lubrication and quietness are achieved by the fluid bearing structure that stores water. By using a
high alloy with high strength and durability in the bearing part, low friction and long life are realized.
Shock absorption rubber pad
By adopting "shock absorption rubber pad", it has excellent vibration absorption and fan stability.
MTBF 100,000 hours long life under 25C environment
Extender cable specifications The
fan cable is usually 30 cm. Can be extended up to 50 cm with an extension cable
Accessories: Extender cable for fan, mounting screw
4-pin PWM connection automatically changes fan speed
92 x 92 x 16 mm thick
Package size / weight
96 (W) × 170 (H) × 20 (D) mm · 105 g
RoHS compliant eco-friendly product
Model number KF9215FD25-P
size 92 x 92 x 16 mm thick
Speed ??(variable PWM) 300 ± 200 to 2500 rpm ± 10%
Noise / air volume 1.8-23.2 dBA / 4.96-41.3 CFM
Static pressure 0.02 ~ 1.36 mmH2O / 0.20 ~ 13.34 Pa
Rated current 0.18 A
Drive voltage 12 VDC
weight 70 g
Fan connection PWM 4 pin
cable length Fan cable 30cm (extendable to 50cm)
bearing Sealed Precision FDB
MTBF 100,000 hours (25C)
