Port
Ports1
ProtocolRS232
ConnectorDB9 Connector - 9 Pin Male
Tx FIFO Size128
Rx FIFO Size256
Operating DistanceEIA - RS232 Standard
CableUSB extender cable (0.25 metre ~ 1ft)
Port Settings
Max Baud Rate921,600
Data Bits7 or 8
ParityOdd, Even, None, Mark or Space
Stop Bits1 or 2
Tx/Rx ModesPoint to Point
General
PCB Layers4
Industrial StandardNo
Power Consumption 40mA @ 5V
Product Weight 0.024 kg, 0.05 pounds
Product Dimensions 89(l) x 35(w) x 20(h) mm


Podporované OS : Windows XP, Vista, 7, Server 2008, Server 2003, Linux, Mac OS X
