Panel
Screen size 65"
Resolution UHD 3840 × 2160
Brightness 500 nits
Typical contrast ratio 1200:1
Dynamic contrast ratio 30,000:1
Viewing angle (H/V) 178°/178°
Response time 8 ms
Backlight life 50,000 hrs
Panel surface AG, Haze 25%
Operating hours 18 hours / 7 days
Orientation Landscape

System
Memory | Storage 8 GB I 128 GB
OS Android 16.0 (EDLA)
GPU Arm Mali-G57 MC2
CPU Octa-Core (A78 × 2 + A55 × 6)
NPU 10 TOPS

Power
Power supply AC 100-240 V, 50/60 Hz
Power
consumption
Typical 68.6 W
Standby <0.5 W
AC power switch Yes
ENERGY STAR® Yes
Wake up LAN / HDMI / VGA

Touch
Technology Precision IR
Number of touch points up to 50
Interface USB Type-B × 2

Glass
Thickness 3.2 mm
Hardness 9H tempered
AG coating Yes

ClassroomCare®
Technology
Eye care: flicker-free
& low blue light Yes (TÜV-certified)
Air quality sensors
& air ioniser No
Germ-resistant screen No

Environment
Operating temperature 0°C ~ 40°C
Operating humidity 20% ~ 80% RH non-condensing

Connectivity
Input VGA × 1, HDMI 2.0 × 3, DP 1.2a × 1, Mic
(3.5mm) × 1, PC Audio × 1
Output HDMI 2.0 × 1, SPDIF (Optical) × 1, Earphone × 1
USB
Type-A × 6 (3.0 × 4 / 2.0 × 2), Type-B × 2
(2.0), Type-C × 3 (3.0 × 1 [5-in-1: data, video,
audio, touch, PD 65 W] / 3.0 × 1 [5-in-1: data,
video, audio, touch, PD 15 W] / 2.0 × 1 [data])
RS-232 (In) × 1
RJ45 (LAN) × 2 (Android / OPS) up to 1000Mbps
Wireless connectivity Optional WD02AT (Wi-Fi 6, Bluetooth 5.2)
OPS slot (for slot-in PC) × 1
Micro SD reader × 1

Built-in
peripherals
Speaker 25 W × 2
Subwoofer 20 W × 1
Microphones 8-mic array, up to 12 m pickup range

Physical
Dimensions (W × H × D) 1483.9 × 911.5 × 87.4 mm
Weight (product | shipping) 36.5 kg | 47.5 kg
Bezel width (T | B | L | R) 35.1 | 47.1 | 14.8 | 14.8 mm
Wall mounting (VESA) (screw
type/max length)
VESA 600 × 400 mm (4 × M8 × 25L),
wall mount kit included

Accessories
Remote control × 1
Stylus × 2 (PT06)
Cables VGA (3 m) × 1, HDMI (3 m) × 1 , USB-B for touch (3 m) × 1
