Display

Model


DHI-LM27-E331Y

LCD Technology


IPS

Backlight


ELED

Screen Size


27 inch

Aspect Ratio


16:9

Viewing Size


596.74 (H) × 335.66 (V) mm

Screen-to-Body Ratio


?90%

Viewing Angle


178° (H)/178° (V)

Display Mode


Horizontal

Pixel Pitch


0.2331 mm × 0.2331 mm (0.0092" × 0.0092")

Pixels Per Inch


108.79

Resolution


2560 (H) × 1440 (V)

Refresh Rate


200 Hz

Display Color


1.07B (8 bits + FRC)

Color Gamut


95% DCI-P3

Color Accuracy


?E<2

Brightness


300 cd/m2 (typ.)

Contrast Ratio


1000:1

Response Time


MPRT 1 ms

Lifespan


30,000 hrs

Operation Hours


7 × 16 H

Surface Treatment


Haze 25%,3H

Flicker-free Technology


Yes

Low Blue Light


Hardware blue light protection

Function

HDR


HDR 10

Device Ports

Input Port


2 × HDMI 2.1 (2560 × 1440@144 Hz), 2 × DP 1.4 (2560 ×1440@200 Hz)

Output Port


1 × Audio out

Power & Environmental Conditions

Power Supply


12 VDC, 4 A

Power Type


power adapter

Power Consumption


26 W (basic), 28 W (typ.), 30 W (max)

Standby Power Consumption


<0.5 W

Operating Temperature


0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity


10% - 85% (RH)

Storage Temperature


-20 °C to +60 °C (-4 °F to +140 °F)

Storage Humidity


5% – 90% (RH)

General

Inclined Angle


-5° / +15°

Product Dimensions


613.8 mm × 362.5 mm × 70.7 mm (24.17" × 14.27" × 2.78") (W × H × D), without wall-mount bracket

Package Size


740 mm × 457 mm × 123 mm (29.13" × 17.99" × 4.84") (W × H × D)

Frame Width


U/L/R/D: 0.09" / 0.09" / 0.09" / 0.69"

Net Weight


4.6 kg (10.14 lb)

Gross Weight


5.9 kg (13.01 lb)

Casing Color


Black

Control Mode


Joystick

Status Indicator Light


Yes

Wall Mount VESA


100 mm × 100 mm (3.94" × 3.94")

Accessory


Power Adapter, Bracket, Base, DP Cable, User Manual (QR Code), Legal and Regulatory Information, Energy Label

Optional Accessory


Wall mount
